Product Introduction

The ABB CI854AK01, part number 3BSE030220R1, is a PROFIBUS DP/V1 communication interface kit designed for ABB AC800M and 800xA distributed control systems. This kit includes CI854 communication module and TP854 baseplate. It acts as a PROFIBUS fieldbus gateway to realize real-time bidirectional data exchange between the AC800M controller and PROFIBUS DP slave field devices, including S800 remote I/O units, variable frequency drives, smart transmitters and other field automation equipment. It supports both PROFIBUS DP cyclic process data transmission and PROFIBUS V1 acyclic parameter access and device diagnosis. Adopting industrial circuit design and excellent EMC anti-interference capability, the module can operate continuously under harsh industrial environments with temperature changes, dust, vibration and strong electromagnetic noise. Widely applied in power, petrochemical, pulp & paper, metallurgy and water treatment industries. It is an important spare part for AC800M rack maintenance, PROFIBUS communication module replacement and legacy DCS system renovation.

Content Details

Brand: ABB Model: CI854AK01 Part No: 3BSE030220R1 Product Type: PROFIBUS DP/V1 Communication Interface Kit Applicable System: ABB AC800M / 800xA DCS Communication Protocol: PROFIBUS DP / V1 Max Baud Rate: 12 Mbit/s Package Includes: CI854 communication module + TP854 baseplate The ABB CI854AK01 3BSE030220R1 kit is mounted on TP854 baseplate inside the AC800M control rack. It connects the controller CEX bus and PROFIBUS DP fieldbus network. It collects field I/O status and measurement data from PROFIBUS slave devices and transmits control commands from the DCS controller to field instruments. It supports high-speed cyclic data communication for process control and acyclic reading and writing of device parameters, diagnosis and alarm information. This module supports hot-swap function. Maintenance engineers can replace the module without shutting down the whole control rack, effectively reducing production downtime during on-site overhaul. Every unit undergoes comprehensive functional testing and aging screening before shipment to guarantee reliable 24/7 continuous operation. Built-in isolation protection suppresses surge and ground loop interference, protecting the main controller from electrical damage caused by fieldbus side faults. It can be configured, debugged and diagnosed via ABB Control Builder software. LED indicators on the front panel display power status, bus activity and fault codes, helping maintenance staff quickly locate bus communication faults, short circuit or device offline issues. It can connect multiple PROFIBUS DP nodes to expand the fieldbus capacity of the AC800M controller. Typical application scenarios include thermal power plant DCS control, chemical continuous process monitoring, paper mill automation, metallurgical production line and municipal sewage treatment automation. When the original PROFIBUS communication module fails, CI854AK01 3BSE030220R1 can be directly replaced to restore PROFIBUS DP/V1 fieldbus communication between DCS controller and field equipment. This module meets CE, UL and IEC industrial safety standards with IP20 protection rating. Compact modular rack design and durable electronic components support long-term continuous operation. Note that this model is not RoHS2 compliant and is mainly used for maintenance and replacement of old automation systems. Whether you prepare spare inventory for equipment maintenance or purchase components for legacy DCS retrofit projects, the ABB CI854AK01 PROFIBUS DP/V1 interface kit provides stable and reliable PROFIBUS fieldbus connection for your AC800M automation system.

Tags: ABB PROFIBUS DP module CI854AK01 3BSE030220R1
