Product Introduction

The ABB PP826 3BSE042244R1 is a compact 5.7-inch function-key HMI panel in ABB Panel800 series, compatible with System 800xA and AC800M controllers. It adopts 320×240 CSTN color display, equipped with multiple dedicated membrane function keys and bi-color LED indicators. Powered by 24VDC, front IP65 protection rating. It supports Ethernet, RS232, RS485 and USB interfaces for real-time process monitoring, manual operation, alarm acknowledgement and event logging. Configuration is finished via Panel Builder 800 software. Widely used in power, chemical, pulp & paper and water treatment industries.

Content Details

ABB PP826 serves as human machine interface for ABB 800xA automation platform. It communicates with AC800M controller over Ethernet to collect field process data, display process graphics and receive operator commands via physical keys. It supports alarm event recording and historical trend storage for on-site fault analysis. Front IP65 rating provides dust and splash resistance for cabinet cutout mounting. Multiple communication ports connect to controllers, and USB interface supports project backup and restore. Built-in hardware diagnostics monitor display, keypad, communication links and internal circuit. With rugged housing and wide operating temperature range, this key panel runs stably under industrial vibration and electromagnetic interference. PP826 is used for engineering commissioning and spare replacement of ABB 800xA DCS. Before shipment, each unit undergoes full functional test and thermal aging inspection to eliminate hidden defects and guarantee reliable long-term continuous operation.
